C0561-71 on a GMC Acadia means: ABS and StabiliTrak disabled because the EBCM received invalid serial data from another module on the CAN bus, most often the BCM.
Fix on the Acadia: clean and re-terminate the BCM ground strap. Cost: $0. Time: 30 minutes.
The GMC Acadia is one of the most common GM SUVs to throw C0561 past 100,000 miles, especially on the 2007–2016 first-generation Lambda platform models that shared a drivetrain with the Chevrolet Traverse, Buick Enclave, and the defunct Saturn Outlook. The 2017+ C1XX platform Acadia still gets the code but somewhat less frequently thanks to improved ground routing.
Here's what C0561 means on the Acadia specifically, the three places to check in order, and the fix that resolves 70% of cases for no parts cost.
In this guide:
What C0561 Means on the Acadia
C0561 on the Acadia is a chassis DTC that translates to "System Disabled Information Stored — Invalid Serial Data Received." The EBCM (ABS/Traction Control module) expected a message from the BCM (Body Control Module) or the ECM (Engine Control Module) over the CAN bus, and either got corrupted data or nothing at all. It stores the code and disables ABS, traction control, and StabiliTrak as a safety fallback.
This is the same underlying fault we document on the C0561 master guide and on the Silverado-specific page — the mechanics are identical. What changes between models is the physical location of the hot-spot wiring and grounds.
Acadia Generation Differences
| Generation | Years | Key Hot-Spot |
| Lambda (1st gen) | 2007–2016 | BCM ground strap at steering column support; ECM-to-EBCM connector at firewall (prone to corrosion in salt-belt states) |
| C1XX (2nd gen) | 2017–2023 | Improved ground routing, but still fails at battery-to-chassis strap on higher-mileage examples. ECM/EBCM connector relocated higher — better. |
| C1TH (3rd gen, 2024+) | 2024+ | Redesigned wiring; C0561 is rare on these so far. Battery weakness is still the main trigger when it does appear. |
Symptoms
- ABS and StabiliTrak lights on simultaneously — the pair is characteristic
- "Service StabiliTrak" message in the driver information center
- Cruise control refuses to engage or kicks off during a drive
- Hill-start assist disabled on 2014+ Acadias
- Adaptive cruise may go inactive on 2017+ Acadias with that option
- Engine and transmission operate normally — C0561 is purely a chassis-system disable, not a powertrain fault
- Code may come and go with weather — cold mornings and rainy days are most common triggers
3 Causes Ranked by Frequency on the Acadia
1. BCM ground strap corrosion — 70% of Acadia cases
The BCM grounds through a braided strap to the steering column support. Over 7–10 years of winter salt, the terminal oxidizes and the mating surface develops a thin film that intermittently blocks ground. Result: EBCM sees voltage drift on the CAN bus → stores C0561-71.
2. Battery voltage drop during cranking — 20% of cases
Acadia batteries (especially on 3.6L V6 Lambda models) drain harder than average due to larger auxiliary loads. A 5-year-old battery that load-tests below 650 CCA will routinely trigger C0561 on cold starts. Replace the battery before chasing deeper issues.
3. ECM-to-EBCM harness connector — 10% of cases
The harness crossing the firewall between the engine ECM and the cabin-side EBCM has a connector that corrodes on salt-exposed Acadias. Symptom: C0561-74 "Engine Torque Signal Invalid." Fix: unplug, clean with CRC 2-26 contact cleaner, apply dielectric grease, reconnect.
Step-by-Step Fix: BCM Ground Strap on the Acadia
- Disconnect negative battery terminal. Wait 60 seconds.
- Find the strap under the dash on the driver's side. On the Acadia it is bolted to the steering column support bracket, just above the pedal assembly. Look for a flat braided copper or tinned strap with a 10mm bolt.
- Remove the bolt. Penetrating oil if it resists.
- Clean both mating surfaces with 80-grit sandpaper down to bare metal on the strap terminal AND the mounting point. Both sides matter.
- Apply dielectric grease thinly.
- Reinstall to 15 ft-lb. Do not over-torque.
- Reconnect battery. Clear all codes with scanner.
- Drive a 20-minute mixed cycle — highway + city — to let the EBCM retest. Lights should stay off.
Repair Cost
| Fix | DIY | Shop |
| Ground strap cleanup | $0 | $80–$140 |
| New ground strap terminal | $8 (eBay) | $120–$180 |
| Battery replacement | $140–$220 (AC Delco/Duralast) | $220–$320 installed |
| ECM-to-EBCM connector clean | $5 (contact cleaner) | $120–$200 |
| BCM replacement (rarely needed) | $180–$340 + dealer programming | $550–$950 |
Do NOT let a shop replace the BCM on your Acadia without a proper diagnosis. We see this shop up-sell repeatedly — a $600+ BCM replacement when a 30-minute ground strap clean would have fixed it.
Frequently Asked Questions
Will the Acadia still drive safely with C0561 active?
Yes, short distances. Base braking and steering still work normally. What you lose is ABS, traction control, StabiliTrak, and on 2014+ trucks, hill-start assist and electronic brake force distribution. Do not drive this way in snow, ice, or heavy rain — a panic stop without ABS is risky.
Does the GMC Acadia Denali have a different fix?
No. The Denali trim shares the same EBCM, BCM, and ground layout as every other Acadia of the same generation. The Denali badge does not change the chassis electronics.
Does C0561 affect the Acadia's transmission or 4WD?
Not directly. The transmission control module and the AWD/4WD electronics operate independently. However, if C0561 appears with U0101 (lost TCM comms), you may see harsh shifts until the comms fault is resolved.
Can a recent aftermarket trailer brake controller cause C0561 on an Acadia?
Yes. If the controller was tapped into the factory 7-way harness using the wrong pin, or if the installer did not use a relay to handle the trailer signal cleanly, the EBCM can see corrupted trailer-brake data and throw C0561-72. Unplug the controller, clear codes, and test.
Is the Acadia's C0561 covered under the emissions warranty?
No. C0561 is a chassis DTC, not an emissions code. The federal 8-year/80,000-mile emissions warranty does not cover it. If your Acadia is still inside the 3-year/36,000-mile bumper-to-bumper, the repair is free at a dealer.
Does the Acadia Limited (2017 final Lambda model) share the same fix?
Yes — the 2017 Acadia Limited was essentially a fleet-sold continuation of the 2016 Lambda Acadia. Same ground strap location, same diagnosis order.
